技術(shù)參數(shù)SPECIFICATIONS
適用線規(guī)(Applicablewires):AWG24#~14#
溫度范圍 (Temperaturerange):-25℃~85℃
額定電壓(Voltagerating):300V.Ac/Dc
額定電流(Currentrating):15Amax
接觸電阻(Contactresistance):≤0.01Ω
絕緣電阻(Insulationresistance):≥1000MΩ
耐壓(Withstandvoltage):2000V.Ac/1min
材料(Material)
殼體(Housing):尼龍(PA66)UL94V-2(0)
端子(Terminal):黃銅(Brass Tin/plated)
